Huasheng Intelligent Immersive System

An immersive audio solution integrating multi-algorithm spatial processing, Dante network transmission and scalable channel architecture. Tailored for theaters, cultural tourism performances and immersive exhibition halls, it elevates auditory experience from surround sound to 3D spatial audio.

We are committed to solving

The drawback that traditional sound reinforcement only delivers audible sound yet fails to create an immersive atmosphere
Huasheng Intelligent Immersive System endows sound with three-dimensional positioning, dynamic movement and immersive perception. Whispers beside ears, sounds rushing from behind and rainfall overhead are all vividly tangible, immersing audiences right in the sound field.

Spacious sound field
Accurate sound source positioning
Dynamic stereoscopic sound

Pain points of traditional sound reinforcement systems

Though line array systems greatly improve sound reproduction in large spaces, they still have notable flaws. The optimal listening area is rather narrow, with accurate stereo sound only available along the central axis. Sound imagery distorts once off-center. Engineers often abandon off-center positioning to secure basic audio quality, which limits expressive potential.

Advantages of Spatial Audio System

Leveraging advanced algorithms, spatial audio systems achieve precise multi-dimensional sound source separation and avoid sound interference, greatly expanding effective listening coverage. It supports programmable dynamic sound sources and real-time vocal tracking, with sound changing synchronously with positions. It empowers creators to produce 3D auditory effects, inspire creativity and break boundaries of stage audio-visual presentation.

Influencing Factors of Spatial Sound Effect

Spatial audio delivers varying degrees of authentic sound source positioning. Such differences are closely related to speaker layout, quantity and power amplifier configuration. Accurate sound presentation across all positions and directions relies on scientific arrangement of speakers. Applicable layouts: front audience area coverage, 180° coverage, 360° coverage, 180°/360° coverage with ceiling-mounted speakers

Live Performance Mixer and Engine（Connection Schematic Diagram）

Detailed Information：

Connection Ports

2 * 2.5Gbps etherCON Ports (Main/Backup)

Audio Redundancy Capability

Non-interruptible redundancy for main and backup ports, maximum 512×512 redundant channels

Supported Sampling Rate

44.1 / 48 / 88.2 / 96 kHz

Sampling Bit Depth

24 bits PCM

Network Delay

< 1 ms

Supported Host Buffer Size

32, 64, 128, 256, 512, 1024, 2048 samples

Network Interface

1×1Gbps etherCON Remote Port
2×2.5Gbps etherCON Dante Port
1×USB3.0(Type A)
1×DisplayPort 4.1

DSP Architecture

24-core DSP Architecture

Storage

500 Go SSD M.2 NVMe

Memory

32 Gb DDR5

Audio Protocol

Dante protocol, compatible with mainstream digital audio workstations and devices with the same protocol, suitable for large venues
